| Video: |
| Video Resolutions |
Up to 8K 60Hz 4:2:0/8K 30Hz 4:4:4/4k 120Hz |
| HDR Formats/Resolutions |
420, 422, 444 (10 AND 12 DEEP COLOR)
HDR10, HDR10+, DOLBY VISION, HLG |
| Color Space |
YUV (Component), RGB
(CSC: Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling |
4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color |
Up to 16 bit (1080P) UP TO 12 BIT (4K) |
| Scaling (Resolution, Output 2 Only) |
8K to 4K or 8K to 2K (1080P) |
| Audio: |
| Audio Formats Supported HDMI |
PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (Digital Toslink) |
LPCM up to 5.1 96KHz 24 Bit, Dolby Digital 5.1, DTS HiRes Audio |
| Audio Formats Supported Extracted (2 CH Port) |
PCM 2 CH |
| Distance: |
| HDMI In/Out (48Gbps) |
UP TO 4 Meters (USING BULLET TRAIN 48Gbps HDMI) |
| HDMI In/Out (W/ AOC Cable) (48Gbps) |
UP TO 100 Meters (USING BULLET TRAIN 48Gbps AOC) |
| Other: |
| Bandwidth |
40 Gbps (FRL 5) |
| HDCP |
HDCP 2.3 and Earlier |
| Ports: |
| HDMI |
Type A |
| Audio (Extracted Analog) |
3.5 mm |
| Audio (Extracted Digital) |
Optical Toslink - Mini Toslink Adaptor included |
| Firmware/Control |
USB-C AND RS232 (3 pin terminal block) |
| Power |
USB-C |
| Environmental: |
| Operating Temprature |
23 to 125°F (-5 to 51°C) |
| Storage Temperature |
-4 to 140°F (-20 to 60°C) |
| Humidity Range |
5-90% RH (No Condensation) |
| Power: |
| Power Consumption (Total) |
2.5 watts max |
| Power Supply |
Input: AC 100-240V ~ 50/60Hz
Output: DC 5V 1A |
| Dimensions: |
| Dimensions (Unit Only Length/Width/Height) |
MM: 64.88 X 100.1 X 16.1
inch: 2.55 X 3.94 X 0.63 |
| Dimensions (Packaged Length/Width/Height) (Kit) |
mm: 136.5 x 155.5 x 88.9
inch: 5.375 x 6.125 x 3.5 |
| Weight (Unit) |
0.32 LBS (0.15 KG) |
| Weight (Packaged) |
0.73 LBS (0.33 KG) |
| *Specifications subject to change without notice. Mass & dimensions are approximate |
