2.1 Channel Compact Amplifier with Audiophile-grade Wolfson Digital-to-Analog Converter
Building upon the success of the Rialto 400 amplifier/DAC with the addition of Volume Control, dual-digital inputs, plus direct or remote IR and RS-232 control, the Rialto 600 is the benchmark solution in local zone audio amplification. A breakthrough, compact, high-powered amplifier with an audiophile-grade Wolfson Digital-to-Analog Converter, the Rialto 600 with variable volume output is an ideal zone solution for local speakers and source playback, analog or digital.
AudioControl’s Rialto 600 provides dramatic audio quality to improve performance in any localized audio zone. Upgrade the sound of analog or digital television audio, including gaming, by adding the Rialto 600 to external speakers. Improve streamed music sources like SONOS, HEOS, and others by transferring their digital signals for ultra-precise decoding by the onboard Wolfson DAC and amplification by the Rialto 600’s authoritative 100 watts into 8 Ohms or 200 watts into 4 Ohms. Low-impedance stable down to 3.6 Ohms, the Rialto may also be bridged for use as a 400-watt monoblock.
The feature-packed Rialto 600 is designed, engineered, and manufactured for the residential and Pro Audio custom installation markets in the rainforest of the Northwest USA, somewhere North of Seattle, and is backed by AudioControl’s renowned 5-year warranty.
Features
- Compact Amplifier and Digital-Analog-Converter (DAC)
- Audiophile-grade Wolfson Digital-Analog-Converter (DAC)
- 2 x 100 watts into 8 Ohms, 200 watts into 4 Ohms
- 400 watts Mono-bridgeable
- Stable Down to 3.6 Ohms
- Preamp Volume Control Via Direct and Remote IR and RS-232
- Source Switching Via Direct or Remote IR and RS-232
- Includes Remote Control
- 2 x TOSLINK & 2 x Coaxial Digital Inputs with Analog Stereo Inputs
- Subwoofer Mono-summed Output
- AudioControl Patented AccuBASS ™ Bass Response
- Built-in, Selectable Electronic Crossover Points
- 12v Trigger Input
- 3.5 mm Headphone Output
- 5-way Binding Posts
- Compact Size at 8.5” W x 5.4” D x 2.9” H
Specifications
INPUTS
Digital Inputs: Optical TOSLINK x 2, Coaxial S/PDIF 75 ohms x 2
Analog Inputs: Stereo RCA x 1
Input Sensitivity: 230mV
Signal Sense Trigger Minimum: 10mV |
CONTROL
12 Volt Trigger Inputs: 1 (mini jack)
IR Inputs: 1 (mini jack)
IR Outputs: 1 (mini jack)
RS-232 Serial Control: Yes |
OUTPUTS
Amplifier Channels: 2
Power Output (8Ω): 100W per channel
Power Output (4Ω): 200W per channel
Minimum Speaker Load: 4Ω
Preamp Outputs: Mono RCA Subwoofer, Mono RCA Bridged |
GENERAL
Power Consumption (typical usage): 40W
Power Consumption (maximum): 520W
Line Voltage: 100-120VAC/200‐240VAC Switchable |
PERFORMANCE
Signal-to-Noise Ratio: >95dB
Frequency Response: 20Hz-20kHz
Total Harmonic Distortion: 0.09% |
WEIGHT & DIMENSIONS
Dimensions: 8.5” W x 5.4” D x 2.9” H
Weight: 6.0lbs (2.7kg) |
| |
IN THE BOX
Rialto 600, RT-1 Remote, Power Cord, Optical TOSLINK Cable, User Manual, Warranty |
