Audio
|
|
|
Amplifier
|
Class-D digital amplifier with GaN and PFFB
|
|
FTC power output rating
|
8 output channels, 125 watt each @ 8Ω (all channels driven)
|
|
Speaker connections
|
Banana plugs (8)
|
|
Minimum impedance
|
2.67Ω with Sonos Architectural speakers
|
|
Line-in sources supported
|
Analog line-level signal via built-in RCA inputs and optional USB-C to 3.5mm adapter
|
|
Analog audio input
|
2 x RCA inputs -10dB (into any zone)
|
|
USB-C analog audio input
|
44.1 kHz / 16 bit (stereo into any zone)
Requires Sonos Line-In Adapter
|
|
Subwoofer connections
|
1 RCA output -10dB, configurable to output from one zone, and 1 Sonos Sub per zone
|
|
Damping factor
|
>400 (ref. 8 ohms, 20 Hz–1 kHz)
|
|
Total harmonic distortion
|
0.005% at 2.83Vrms-15Vrms
|
|
Frequency response
|
±0.5 dB, 15 Hz - 20 kHz
|
|
Channel separation (Crosstalk)
|
-100dB at 1 kHz 2.83Vrms
-80dB at 10 kHz 2.83Vrms
|
|
Signal-to-noise ratio
|
114dB ref 125W into 8-Ohm
|
|
Integrated content streaming
|
Amazon Music, Apple Music, Cloud Cover Music, Mood Media, Sonos Radio, Soundtrack Your Brand, Spotify, and many more.
For a complete list, please visit: support.sonos.com/services
|
|
Details & Dimensions
|
|
|
Product dimensions (W x H x D)
|
17.2 x 2.52 x 10.44 in (436.8 x 64.5 x 265.2 mm)
|
|
Net weight
|
11.17 lb (5.06 kg)
|
|
Shipping weight
|
16.56 lb (7.51 kg)
|
|
Colors
|
Black
|
|
Finish
|
Matte
|
|
LEDs
|
Front: Device status
Rear: Device status, output status (x8), RJ45 status light
|
|
Operating temperature
|
32° to 95° F (0 to 35° C)
|
|
Storage temperature
|
-4° to 122° F (-20° to 50° C)
|
|
Humidity range
|
Operates in non-condensing humidity 10–85%
|
|
Power & Connectivity
|
|
|
Power supply
|
Auto-switching 100-240V 50/60 Hz 10A AC universal input
|
|
Power consumption
|
5.4 W (idle)
180 W (all channels driven at 1/8 output power, 8Ω)
|
|
Wired Networking Interface
|
100BaseTX, Ethernet RJ45
|
|
Wireless Networking Interface
|
Compatible with WiFi 6. Connect to WiFi with any 802.11a/b/g/n/ac/ax 2.4 GHz/5 GHz broadcast-capable router.
|
|
CPU
|
Quad Core
4xA55 1.9 GHz
|
|
Apple AirPlay
|
Works with AirPlay 2 on Apple devices iOS 11.4 and higher.
|
|
Direct Streaming Formats
|
Apple AirPlay 2, Spotify Direct Control
|
|
What's in the box?
|
|
|
Product
|
1 Amp Multi
|
|
Banana plugs
|
8 custom Sonos banana plugs
|
|
Ferrite clamp
|
1 ferrite clamp
|
|
Power cable
|
AC power cord
|
|
Documentation
|
Quickstart Guide (printed on the box) and legal/warranty information
|
|
Requirements
|
|
|
Passive speakers
|
Passive speakers with speaker wire
|
|
Internet connection
|
Access to the internet
|
|
Sonos app
|
The latest generation of the Sonos app running on a compatible device
|
