55” SVH7F Series 0.44mm Even Bezel FHD IPS Video Wall with built-in SoC and webOS Smart Signage Platform, Gap Reduction and Smart Calibration
PANEL
- Screen Size - 55"
- Panel Technology - IPS RGB
- Aspect Ratio - 16:9
- Native Resolution - 1,920 x 1,080 (FHD)
- Brightness (Typ., nits) - 700
- Contrast Ratio - 1,200:1
- Viewing Angle (H x V) - 178 x 178
- Response Time - 8 ms (G to G)
- Surface Treatment - Haze 3%
- Life Time (Typ.) - 60,000 Hrs
- Operation Hours - 24 Hrs
- Orientation - Landscape & Portrait
CONNECTIVITY
- Input - HDMI (2), DP, DVI-D, Audio, USB
- Output - DP, Audio
- External Control - RS232C In/Out, RJ45 (LAN) In/Out, IR In
MECHANICAL SPECIFICATION
- Bezel Color - Black
- Bezel Width - 0.44 mm (Even)
- Monitor Dimension (W × H × D) - 1,210.51 x 681.22 x 86.5 mm
- Weight (Head) - 16.8 kg
- Carton Dimensions (W × H × D) - 1,353 x 855 x 263 mm
- Packed Weight - 23.6 kg
- Handle - Yes
- VESA™ Standard Mount Interface - 600 x 400 mm
ENVIRONMENT CONDITIONS
- Operation Temperature - 0°C to 40°C
- Operation Humidity - 10 % to 80 %
POWER
- Power Supply - 100-240V~, 50/60Hz
- Power Type - Built-In Power
POWER CONSUMPTION
- Typ. - 210 W
- Max. - 250 W
STANDARD(CERTIFICATION)
- Safety - CB / NRTL
- EMC - FCC Class "A" / CE / KC
- ErP - Yes (EU Only)
MEDIA PLAYER COMPATIBILITY
- OPS Type Compatible - Yes (Piggyback)
SOFTWARE COMPATIBILITY
- Content Management Software - SuperSign CMS
- Control and Monitoring Software - SuperSign Control / Control+
ACCESSORY
- Basic - Remote Controller, Power Cord, RS232C Cable, LAN Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual
- Optional - Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), OPS Kit(KT-OPSF)
KEY FEATURES
- Brightness(Typ.) : 700 nits
- Bezel : 0.44 mm (Even)
- Depth : 86.5 mm
- Interface : HDMI(2)/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
- Smart Calibration
0.44mm EVEN BEZEL VIDEO WALL
Making use of LG's pioneering display technology, the extremely slim 0.44mm Even Bezel Video Wall unlocks great display opportunities, even in markets that previously avoided video walls due to the visible bezel. The razor-thin bezel of 55SVH7F – 0.44mm Even Bezel and 0.88 Bezel to Bezel – depicts content in a virtually true to form look and has been verified by Nemko*.
VIVID AND DYNAMIC PICTURE QUALITY
Higher Viewing Angle
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the 55SVH7F-A is superior to that of conventional video walls, allowing it to display vivid colors throughout the screen with no distortion.
*Results based on in-house testing. Actual test results may differ depending on environment and measuring equipment.
**Images are for illustrative purposes only.
VIVID AND DYNAMIC PICTURE QUALITY
Wider Viewing Angle
LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the 55SVH7F-A captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.
VIVID AND DYNAMIC PICTURE QUALITY
Uniform Color Expression
Poor uniformity around bezel boundaries can give the corners a darker appearance, which doesn’t look good on a large screen. However, the 55SVH7F-A has enhanced uniformity, even within the four corners of the display, to deliver vivid and consistent color throughout the screen.
*Uniformity among 13 points of the screen. Results based on in-house testing. Actual test results may differ depending on environment and measuring equipment.
**Images are for illustrative purposes only.
VIVID AND DYNAMIC PICTURE QUALITY
Image Gap Reduction
The 55SVH7F-A includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.
*The "Conventional" refers to displays which do not include an image improvement algorithm.
**Images are for illustrative purposes only.
Smart Calibration
Smart Calibration is a solution that enables error-free calibration while dramatically reducing time and costs compared to existing sensor calibration methods. It analyzes luminance within each individual display and exchanges that data between the connected displays to ensure maximum uniformity.
*Images are for illustrative purposes only.
POWERFUL SMART SIGNAGE PLATFORM
High Performance and Great Scalability
Thanks to its built-in SoC and webOS smart signage platform, the 55SVH7F-A can execute several tasks at once while providing smooth content playback without the need for a media player.
POWERFUL SMART SIGNAGE PLATFORM
Flexible Content Creation
Four different videos can be played simultaneously via web apps, and various animation effects, such as scaling or rotating, are added to content using Cascading Style Sheets (CSS) transition effects. Real-time streaming* is also available, providing the flexibility to organize and diversify content free from capacity limits.
* Supported protocols : RTSP. RTP, HLS, UDP Multicast.
USER-FRIENDLY SMART SIGNAGE UX
Intuitive Menu Structure
The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.
USER-FRIENDLY SMART SIGNAGE UX
Dedicated GUI for Portrait Orientation
The conventional Graphic User Interface (GUI) was designed based on landscape-oriented consumer TV usage, so On Screen Display (OSD) wasn’t well-suited for screens in portrait mode. The OSD of the 55SVH7F-A, however, consists of a long range menu with bigger font sizes and a 9:16 ratio, creating a comfortable business environment.
USER CONVENIENCE
Easy Color Adjustment
Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.
USER CONVENIENCE
Simple White Balance Adjustment
In conventional video walls, white balance was adjustable only in “full-white” mode, but the 55SVH7F-A allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.
USER CONVENIENCE
LAN Daisy Chain Management
A LAN daisy chain allows you to execute commands to control and monitor video walls and even update their firmwares at once.
USER CONVENIENCE
Real-time ConnectedCare Service
Maintenance is easy and fast with the optional ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.
*ConnectedCare is the brand name of LG Signage365Care Service. Availability differs by region.
