The STEALTH 360 from RAB Lighting is the most reliable and technically advanced motionactivated light control ever produced. Its infrared sensor “sees” temperature changes caused by the motion of people or cars within its protection zone and turns on lights automatically, welcoming visitors and deterring intruders.

Two powerful sensors combine to provide can’t-miss, total-coverage detection: 180º long forward range (180º x 60’) plus superb 360º detection below and to all sides. Visible LEDs alert visitors that a security device is in operation. When the device stands guard in Auto Mode, three red LEDs scan continuously day and night to detect infrared changes that trigger on lighting.  When the sensor is set for Manual Override Mode, the middle LED will remain on steadily. In the Evening Timer Mode, the sensor’s middle LED will blink. Once triggered, lights remain on as long as there is movement within the protection zone. Once the zone is vacated lights can be adjusted to remain on from approximately 5 seconds up to 12 minutes. Since the lights are on only when needed, and the sensor uses just one watt, the Stealth is extremely energy efficient.

• Senses 180° out + 360° down for total detection

• Scanning LED's

• Radio frequency immunity

• 6000 volt surge protection

• 1000 Watt switching capacity

• Pre-wired and pre-assembled on CU4 universal EZ plate

• Protected manual override with auto reset

• Can be wired in parallel

Compliance:

• UL Listed: Suitable for wet locations

Electrical:

• Voltage:120 volts AC 60 Hz
• Power Consumption: 1W
• Surge Protection: Withstands up to 6000 volts
• Wall Switch Manual Override: Two flip logic prevents activation by momentary power outages. Override resets to auto at dawn. No extra wiring needed.
• RF Immunity: Circuits fully shielded for maximum radio frequency immunity
• Switching Capacity: 8 amps, 1000 watts incandescent @ 120 volts

Sensor Specifications:

• Time Adjustment: 5 seconds to 12 minutes
• Wide Sensitivity Control: Adjustable from 100% to 30%
• Evening Timer: Keeps lights on for 1-8 hours after dusk. Then sensor is motion activated until dawn.
• Set it and forget it: STL360's full coverage pattern reduces need for aiming and adjustment
• Advanced Detection Logic: Minimizes false triggers
• Photoelectric Control: Deactivates lights during daylight. Fully adjustable for 24 hour operation or custom applications.
• Detection: Senses 180° and 360° down for Total Detection

LED Characteristics:

• Scanning LEDs: 3 LEDs continually scan back-and-forth
• Color Matched Lens: Dark lens with bronze units, white lens with white units

Construction:

• Temperature Compensation: Sensitivity adjusted automatically for consistent detection in hot and cold ambient temperatures
• Mounting: CU4 plate allows the sensor to be mounted under a soffit
• Lens Masks: Customized press apply lens mask included to reduce coverage easily

Other:

• Warranty: 10 year sensor warranty
• Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
